3 - 7

Back, Top, and Left Panels

Dolphin 70e Black Models Equipped with a Battery Door Lock

Note: If your Dolphin 70e Black model does not have a battery door lock, see page 3-8.

For a description of each callout, see page 3-9.

Image Engine Window (LED Aperture)

Camera Flash

Color Camera Lens

Battery Latch (battery and

battery door not shown)

SIM Card Socket*

Power Button

Left Scan/Image Button

I/O Connector

(see page 3-11)

Audio Jack

Volume Control Button

Battery Door

(Standard Model Shown)

Memory Retention Flap

SIM Card Retention Flap*

Memory Card Socket with microSD Card (pre-installed)

* WWAN equipped models only

Battery Door Lock
